Coal Loader Platform Green Roof

Due Completion: 24 March 2018

The Coal Loader Platform opened on 24 March 2018.

Project Background

The last main stage of the redevelopment of the Coal Loader Centre for Sustainability - a major milestone of the Waverton Peninsula Strategic Master Plan - has been the creation of one of Sydney’s largest publicly accessible green roof spaces.

On the old coal-loading platform, the concrete and sandstone structure is one hectare (seven Olympic-sized swimming pools would fit side by side along its length) and designed to be a multi-purpose recreational space with spectacular views of the harbour.

The green roof project includes community "urban harvest" plots (vegetables, fruit trees, aquaculture) irrigated by recycled stormwater, a performance space, extensive seating and viewing areas, as well as heritage interpretation of the original coal loading operations. Up to 250,000 litres of collected stormwater can be filtered through ‘raingardens’ established in the old coal loading chutes and stored in one of the old tunnels beneath the platform. Skylights over the existing pedestrian tunnel provide natural light to augment internal lighting.

A colonnade along the western edge provides shelter from sun and rain and supports special integrated solar panels that, together with sun-tracking panels at the south end of the platform, generates electricity to offset the site's power requirements - by 100%!

Grape vines will eventually be planted to grow along the colonnade (based on heritage varieties originally imported by Alexander Berry – the original British settler of the area). These vines will provide summer shade, while being view-friendly, plus the grapes can be harvested for wine-making. A demonstration area at the southern end of the platform provides guidance on the best local Australian plants for green-roof environments.

The platform provides opportunities for learning and social interaction in an "outdoor classroom" environment - in keeping with the’ hands-on’ philosophy of the Centre for Sustainability.

A range of smart technologies and sensors monitor key environmental parameters and this information will be fed back to a website portal, allowing remote interaction, research and analysis by schools, universities and other interested groups.
